Vacuum Pump

Name: Vacuum Pump
Brand: MAHAVIR ENTERPRISES
Price: 5000.0 INR
Availability: InStock

Price 5000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Vacuum Pump Specification

Connector Type
Threaded

Humidity %
Max 85%

Surface Finish
Powder Coated

Insulation Material
Class F Insulation

Efficiency
High

Shape
Rectangular

IP Rating
IP54

Power Factor
0.95

Overheating Protection
YES

Mounting Type
Base Mounted

Feature
Oil-lubricated, Compact Design

Operating Temperature
-10C to 40C

Product Type
Rotary Vane Vacuum Pump

Application
Industrial, Laboratory, Pharmaceutical

Protection Level
IP54

Frequency (MHz)
50 Hz

Rated Voltage
220V

Energy Consumption
Low

Output Type
Vacuum

Color
Blue-Grey

Dimension (L*W*H)
340 x 150 x 210 mm

Weight
18 kg

Size
Medium

Phase
Single Phase

Input Voltage
220V

Material
plastic and brass

Connection Type
Flange/Threaded

Cooling Type
Air Cooled

Motor Power
0.5 HP

Ultimate Vacuum
0.05 mbar

Noise Level
< 60 dB(A)

Serviceability
Easy to Maintain

Pumping Speed
150 L/min

Inlet/Outlet Port Size
1/2 inch BSP

Displacement
8 m3/hr

Oil Capacity
600 ml

Vacuum Pump Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Month

Delivery Time
7 Days

About Vacuum Pump

*vacuum pump rate is various starting from 3000/- to 25,000/- .
We are engaged in offering a wide range of quality products to our clients. Our range of all products is widely appreciated by our clients.

Efficient and Reliable Vacuum Performance

Delivering an ultimate vacuum of 0.05 mbar and a rapid pumping speed of 150 L/min, this vacuum pump stands out for its dependable results. It operates efficiently in diverse industrial and laboratory environments, maintaining high performance under continuous use. The oil-lubricated mechanism and sturdy Motor Power of 0.5 HP guarantee both durability and smooth operation, making it a preferred choice for critical applications.

Designed for Safety and Easy Maintenance

Equipped with IP54-rated protection, Class F insulation, and integrated overheating safeguards, this vacuum pump prioritizes safety. Maintenance is simplified through its accessible design and easy oil changes, while the powder-coated finish and corrosion-resistant materials keep the unit in optimal condition for years. Base mounting and compact dimensions ensure straightforward installation in various settings.

Versatile for Multiple Applications

Suitable for industrial, laboratory, and pharmaceutical use, this vacuum pump accommodates a range of vacuum needs. Its medium size, robust air-cooling system, and efficient energy consumption make it adaptable for different operational environments, from research facilities to manufacturing floors. The blue-grey, rectangular design provides both aesthetic appeal and practical compactness.

FAQ's of Vacuum Pump:

Q: How do I maintain this vacuum pump to ensure optimal performance?

A: Regular maintenance involves monitoring the 600 ml oil level, replacing the oil as needed, and checking for debris in the air-cooling system. The easy-to-maintain design allows for straightforward servicing, so periodic visual inspections and cleaning are recommended for sustained efficiency.

Q: What types of applications is this vacuum pump suitable for?

A: This vacuum pump is engineered for industrial, laboratory, and pharmaceutical uses, including vacuum filtration, distillation, drying, and other processes requiring clean and consistent vacuum. Its robust build, efficiency, and low noise level make it versatile across numerous demanding domains.

Q: When should I expect to carry out oil changes for this vacuum pump?

A: Oil changes depend on the frequency and intensity of operation, but for industrial and laboratory environments, inspecting and replacing the oil every 500-700 hours of use or according to workload is recommended. Always use appropriate vacuum pump oil for best results.

Q: Where can this pump be installed, and what mounting options are available?

A: This medium-sized, base-mounted pump can be installed on stable surfaces in industrial facilities, laboratories, and pharmaceutical environments. Its base-mounted configuration ensures secure and vibration-minimized placement, while the compact dimensions allow for easy integration into restricted spaces.

Q: What is the process for connecting the pump to existing systems?

A: The pump features 1/2 inch BSP inlet and outlet ports, compatible with both flange and threaded connectors. Simply align and attach the appropriate fittings to your vacuum lines, ensuring all connections are tight to avoid leakage and maximize vacuum performance.

Q: How does this vacuum pump benefit energy efficiency and workplace comfort?

A: Engineered for low energy consumption with a power factor of 0.95, the pump helps lower operational costs. It operates at less than 60 dB(A), minimizing noise pollution and creating a more comfortable and safe working environment.

Q: What features protect the pump from overheating and environmental factors?

A: The pump incorporates advanced overheating protection and Class F insulation, while the IP54 rating safeguards against dust and splashing water. These features ensure consistent, safe operation even in environments with higher temperatures or humidity levels up to 85%.
